THE PROTOTYPE / GUIDED WALKTHROUGH
From a signal.
To understanding.
Explore the reasoning workflow, one screen at a time. Scroll or choose a step.
Interactive illustration with synthetic data. No AI request or real diagnosis is performed.
Explore the demo ↓Start with the right vehicle.
Set the vehicle, engine and reported symptoms before interpreting a code.
Bring the signals together.
A code is an input. Its source and compatibility still need to be checked.
Follow the evidence.
Separate observations, missing information and interpretation.
Keep the technician in control.
Keep a traceable record of the context, evidence and next checks.
Volkswagen Golf
2018 · 1.6 TDI · Synthetic example
- Engine
- 1.6 TDI
- Mileage
- 126 400 km
- Context
- Intermittent warning light
A code, not a verdict.
- Source
- Workshop input
- Vehicle compatibility
- To be checked
A fault code alone does not justify replacing a part.
Make uncertainty visible.
- 01Record observations
Describe when the warning appears.
- 02Verify the source
Confirm applicability to this vehicle.
- 03Add measurements
Evidence before a conclusion.
A clear next step.
ORVECT / CASE 001
Human review required
Vehicle context, observed signals and missing evidence in one record.
This demo does not authorize driving or a repair.
ORIGINAL INTERFACE CAPTURES · ENGLISH
Inside the workspace.
These original captures remain in English. All screens in the guided demo above follow your selected language.
Open the prototype ↗FROM DEMO TO FEEDBACK
Your next case.Starts here.
You have explored the workflow. Join the beta to help shape it around the realities of your workshop.
Sign up for the beta
